性能特點:
1、含油量0級的高標準無油壓縮空氣；
2、壓縮過程沒有潤滑油參與，確保壓縮空氣不含潤滑油；
3、特殊的密封件設計，完全隔絕潤滑油進入壓縮腔；
4、電機變頻控制，智能匹配轉速，保證穩(wěn)定的排氣壓力；
5、電機采用工頻或永磁變頻控制，提高節(jié)能效果；
6、性能范圍：介質：空氣、氮氣、工藝氣等；啟動方式：工頻或變頻；流量：3~100m3/min；升壓：30~150kpa；
| 主機型號 | 電機轉速 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | ||
| 排氣壓力 | 40Kpa | 50Kpa | 60Kpa | 70Kpa | 80Kpa | 90Kpa | |||||||
| HDLG300 | 2000.0 | 3375.0 | 66.2 | 3360.0 | 73.3 | 3353.0 | 81.2 | 3346.0 | 89.0 | 3339.0 | 96.9 | 3331.0 | 104.8 |
| 2100.0 | 3579.0 | 69.2 | 3564.0 | 76.6 | 3556.0 | 84.9 | 3549.0 | 93.1 | 3541.0 | 101.3 | 3533.0 | 109.6 | |
| 2200.0 | 3788.0 | 72.2 | 3771.0 | 80.0 | 3763.0 | 88.6 | 3755.0 | 97.2 | 3747.0 | 105.8 | 3739.0 | 114.3 | |
| 2300.0 | 4000.0 | 75.2 | 3983.0 | 83.3 | 3974.0 | 92.2 | 3966.0 | 101.2 | 3957.0 | 110.1 | 3948.0 | 119.1 | |
| 2400.0 | 4216.0 | 78.2 | 4198.0 | 86.5 | 4189.0 | 95.8 | 4180.0 | 105.1 | 4171.0 | 114.4 | 4162.0 | 123.8 | |
| 2500.0 | 4436.0 | 81.1 | 4417.0 | 89.8 | 4407.0 | 99.4 | 4398.0 | 109.1 | 4388.0 | 118.7 | 4379.0 | 128.4 | |
| 2600.0 | 4660.0 | 84.0 | 4640.0 | 93.0 | 4630.0 | 103.0 | 4620.0 | 113.0 | 4610.0 | 123.0 | 4600.0 | 133.0 | |
| 2700.0 | 4854.0 | 87.2 | 4833.0 | 96.6 | 4823.0 | 107.0 | 4812.0 | 117.3 | 4802.0 | 127.7 | 4791.0 | 138.1 | |
| 2800.0 | 5049.0 | 90.5 | 5027.0 | 100.2 | 5016.0 | 110.9 | 5005.0 | 121.7 | 4994.0 | 132.5 | 4984.0 | 143.2 | |
| 2900.0 | 5245.0 | 93.7 | 5222.0 | 103.7 | 5211.0 | 114.9 | 5200.0 | 126.0 | 5188.0 | 137.2 | 5177.0 | 148.3 | |
| 3000.0 | 5442.0 | 96.9 | 5418.0 | 107.3 | 5407.0 | 118.8 | 5395.0 | 130.4 | 5383.0 | 141.9 | 5372.0 | 153.5 | |
| 3100.0 | 5640.0 | 100.2 | 5616.0 | 110.9 | 5604.0 | 122.8 | 5592.0 | 134.7 | 5579.0 | 146.7 | 5567.0 | 158.6 | |
| 3200.0 | 5839.0 | 103.4 | 5814.0 | 114.5 | 5802.0 | 126.8 | 5789.0 | 139.1 | 5777.0 | 151.4 | 5764.0 | 163.7 | |
| 3300.0 | 6040.0 | 106.6 | 6014.0 | 118.0 | 6001.0 | 130.7 | 5988.0 | 143.4 | 5975.0 | 156.1 | 5962.0 | 168.8 | |
| 排氣壓力 | 100Kpa | 110Kpa | 120Kpa | 130Kpa | 140Kpa | 150Kpa | |||||||
| HDLG300 | 2000.0 | 3317.0 | 112.7 | 3310.0 | 120.5 | 3295.0 | 128.4 | 3281.0 | 136.3 | 3266.0 | 144.2 | 3252.0 | 152.1 |
| 2100.0 | 3518.0 | 117.8 | 3510.0 | 126.1 | 3495.0 | 134.3 | 3480.0 | 142.5 | 3464.0 | 150.8 | 3449.0 | 159.0 | |
| 2200.0 | 3723.0 | 122.9 | 3715.0 | 131.5 | 3698.0 | 140.1 | 3682.0 | 148.7 | 3666.0 | 157.3 | 3650.0 | 165.9 | |
| 2300.0 | 3931.0 | 128.0 | 3923.0 | 137.0 | 3905.0 | 145.9 | 3888.0 | 154.9 | 3871.0 | 163.8 | 3854.0 | 172.8 | |
| 2400.0 | 4144.0 | 133.1 | 4135.0 | 142.4 | 4116.0 | 151.7 | 4098.0 | 161.0 | 4080.0 | 170.3 | 4062.0 | 179.6 | |
| 2500.0 | 4360.0 | 138.1 | 4350.0 | 147.7 | 4331.0 | 157.4 | 4312.0 | 167.0 | 4293.0 | 176.7 | 4274.0 | 186.3 | |
| 2600.0 | 4580.0 | 143.0 | 4570.0 | 153.0 | 4550.0 | 163.0 | 4530.0 | 173.0 | 4510.0 | 183.0 | 4490.0 | 193.0 | |
| 2700.0 | 4770.0 | 148.5 | 4760.0 | 158.9 | 4739.0 | 169.3 | 4718.0 | 179.7 | 4698.0 | 190.0 | 4677.0 | 200.4 | |
| 2800.0 | 4962.0 | 154.0 | 4951.0 | 164.8 | 4929.0 | 175.5 | 4908.0 | 186.3 | 4886.0 | 197.1 | 4864.0 | 207.8 | |
| 2900.0 | 5155.0 | 159.5 | 5143.0 | 170.7 | 5121.0 | 181.8 | 5098.0 | 193.0 | 5076.0 | 204.1 | 5053.0 | 215.3 | |
| 3000.0 | 5348.0 | 165.0 | 5337.0 | 176.5 | 5313.0 | 188.1 | 5290.0 | 199.6 | 5267.0 | 211.2 | 5243.0 | 222.7 | |
| 3100.0 | 5543.0 | 170.5 | 5531.0 | 182.4 | 5507.0 | 194.3 | 5483.0 | 206.3 | 5458.0 | 218.2 | 5434.0 | 230.1 | |
| 3200.0 | 5739.0 | 176.0 | 5727.0 | 188.3 | 5702.0 | 200.6 | 5676.0 | 212.9 | 5651.0 | 225.2 | 5626.0 | 237.5 | |
| 3300.0 | 5936.0 | 181.5 | 5923.0 | 194.2 | 5897.0 | 206.9 | 5871.0 | 219.6 | 5846.0 | 232.3 | 5820.0 | 245.0 | |
